Signal converter 2 x DVB-T into 6 x ASI
plugin card for modular base unit V 16
Specification
| Module type | Plug-in card |
|---|---|
| Input signal | DVB-T |
| Output signal | ASI |
| Order number | 00380208 |
|---|---|
| EAN-Code | 4026187680237 |
V 241
No longer available
Product Details
- plugin card for modular base unit V 16
- processing of 2 independent COFDM input signals into ASI data streams
- routing per software to up to 6 outputs
- postprocessing of streams with the ASTRO IP-Gateway U 262 or with any other ASI transportstream ckompatible equipment (e.g. multiplexer)
Download Details
-
Blockschaltbild V 241_V 241 CI pdf · 2mb
-
Datenblatt V 241_V 241 CI pdf · 2mb
-
Datenblatt V 241_V 241 CI [en] pdf · 2mb
